laboratory stainless steel stirred pressure reactor
This series stirred pressure reactor; Stainless steel Lab pressure reactor is widely used in laboratory application. 100ml to 5 liters volume; Standard 100bar, maximum up to 350bar; Temperature standard 350C, maximum up to 400℃; Standard materials:SS-304, SS-316, other alloys, etc.
-
Lift&flip laboratory high pressure reactor
2L;SS316,PTFE lner;100bar;200℃;Lift&flip device;Magnetic coupling drive Our pressure reactor could service wide range of industrial company, like environmental protection in petroleum, chemical industry, medicine, dyes, mining and metallurgy, scientific research institutes, colleges (chemical, polymer, material engineering, organic and inorganic chemical). Pressure range 0.1-50MPa, volume range 0.1L-50,000L. High pressure reactor vessel | high pressure autoclave reactor | lab mini autoclave reactor | Reaction autoclave
-
PTFE Lined Lab Pressure Reactor With Lifting Lowering functions
Floor stands or moveable cart type. Laboratory autoclaves with 500 ml to 5 liters volume. Max pressure: 300 bar; Max temperature up to 200 ℃ High pressure reactor vessel | Low to high torque magnetic couplings: static seal with no leakage. Available material:SS304, SS316, Titanium, Nickel, Hastelloy B/C, Monel, Zirconium, Inconel, Tantalum. Lifting device for easy operation,low labor cost. Monitor and control: Temperature, pressure, motor speed, gas / liquid flow, level, etc Safety Device (Blasting Disc) on Security Blasting Port. Customized according to customers requirement.
-
high pressure reaction system with vacuum pump
Reactor system;1L;100bar;Lift&tilt;480℃;Electric heating;Magnetic seal The system is designed to enable comfortable and efficient work. 1L lab continuous stirring reactor with vacuum pump HUIXIN offers two styles of condensers for attachment to the head of a stirred reactor or pressure vessel. These can be made in various sizes to match the size of the reactor. Quick opening pressure autoclaves | Lift For Pressure Reactors | Lab lifting reactor | Electric lifting pressure reactors
-
Miniature mechanical stirring high pressure reactor
GSHK-0.25 (Lift & rotation device; Quick open.); 250ml;SS304+PTFE liner bowl;100bar; 220℃;RS-485 Our pressure reactor could service wide range of industrial company, like environmental protection in petroleum, chemica lindustry, medicine, dyes, mining and metallurgy, scientific research institutes, colleges (chemical, polymer, material engineering, organic and inorganic chemical). Pressure range 0.1-50MPa, volume range 0.1L-50,000L. Reactor material could be Stainless Steel, Titanium, Nickel, Hastelloy, Monel, Inconel and other special materials …etc.
-
Lab agitated pressure hydrogenation reactor with manual lifting
Movable stirred pressure autoclaves | Floor stands or moveable cart type. Laboratory autoclaves with 250 ml to 5 liters volume. Max pressure: 200 bar; Max temperature up to 500 ℃ Low to high torque magnetic couplings: static seal with no leakage. Available material:SS304, SS316, Titanium, Nickel, Hastelloy B/C, Monel, Zirconium, Inconel. Lifting and tilting device for easy operation,low labor cost. Moveable head quick openning design. Monitor and control: Temperature, pressure, motor speed, gas / liquid flow, level, etc Safety Device (Blasting Disc) on Security Blasting Port. Customized according to customers requirement.
-
Lab pressure reactors with head lifting & lowering
100ml/ 250ml/500ml/1liters/2liters/5liters Standard 100bar,Up to 350bar Standard 350℃,up to 500℃ Material:SS304/SS316, titanium,hastelloy,PTFE liner. Manual lifting pressureautoclaves | Application: Chemical development; High pressure none leakage application; Corrosion test, and catalyst test; Scale-up;Pilot-Plant; Small-scale production Hydrogenation;Catalytic Reaction;Polymerization; Electric lifting pressure reactors | Lab lifting reactor
-
Manual lifting lab stirred pressure autoclaves
Lifting high pressure reactors | High pressure lifting reactor | Lab lifting reactor Lifting/Lowering reactors | Electric lifting pressure reactors | Pheumatic lifting pressure reactors 100ml/ 250ml/500ml/1liters/2liters/5liters Standard 100bar,Up to 350bar Standard 350℃,up to 500℃ Material:SS304/SS316, titanium,hastelloy,PTFE liner. Lifting pressure reactors | GSHK series Laboratory autoclave with coil cooling can also set the following options: *Quick open design(split clamp with clamp bolts) *Floor stand or moveable cart design *Direct drive or belt drive optional *Reactor lift / lowering / Tilting device. *Magnetic and mechanical seal. *Vacuum pump, Heating & cooling circulator, PLC control and others. *Various impeller type available for mixing mission. *Various Anti-corrosion alloy material available.
-
Hastelloy C276 made Stirred Lab pressure reactor with lift and tilt
Vertical stirred autoclaves | Floor stands or moveable cart type. Laboratory autoclaves with 250 ml to 5 liters volume. Max pressure: 200 bar; Max temperature up to 500 ℃ Low to high torque magnetic couplings: static seal with no leakage. Available material:SS304, SS316, Titanium, Nickel, Hastelloy B/C, Monel, Zirconium, Inconel, Tantalum Lifting and tilting device for easy operation,low labor cost. Monitor and control: Temperature, pressure, motor speed, gas / liquid flow, level, etc Safety Device (Blasting Disc) on Security Blasting Port. Customized according to customers requirement.
-
Fast Opening/closure lab high pressure reactor
Quick opening pressure reactor | Floor stands or moveable cart type. Laboratory autoclaves with 250 ml to 5 liters volume. Max pressure: 200 bar; Max temperature up to 500 ℃ Low to high torque magnetic couplings: static seal with no leakage Available material:SS304, SS316, Titanium, Nickel, Hastelloy B/C, Monel, Zirconium, Inconel, Tantalum. Lifting and tilting device for easy operation,low labor cost. Moveable head quick openning design. Monitor and control: Temperature, pressure, motor speed, gas / liquid flow, level, etc Safety Device (Blasting Disc) on Security Blasting Port. Customized according to customers requirement.
-
Electric lifting laboratory stirred catalyst Reactor
Electric lifting function set for automatic cover lid lifting and lowerring 100ml/ 250ml/500ml/1liters/2liters/5liters Standard 100bar,Up to 350bar Standard 350℃,up to 500℃ Material:SS304/SS316, titanium,hastelloy,PTFE liner. Electric Lifting pressure reactors | GSHK series Laboratory autoclave with coil cooling can also set the following options: *Quick open design(split clamp with clamp bolts) *Floor stand or moveable cart design *Direct drive or belt drive optional *Reactor lift / lowering / Tilting device. *Magnetic and mechanical seal. *Vacuum pump, Heating & cooling circulator, PLC control and others. *Various impeller type available for mixing mission. *Various Anti-corrosion alloy material available.
-
450bar high pressure reactor with head lift & vessel rotate
Pressure up to 450bar,electric heating,head lift & vessel rotate Lift for pressure reactors | This series stirred pressure reactor is widely used in laboratory application, which have features as fellows: 100% Sealing. Zero leakage. Low energy cost magnetic stirrer. The top cover and the kettle body are connected by flange bolts. Vessel body can be manual rotate for discharge; Top cover lid & magnetic agitator can be manual lifting & lowering
